تفاصيل المنتج:
|
| Inner Cylinder Material: | stainless stain | Max Working Pressure: | 2.16mpa |
|---|---|---|---|
| Operating Temperature: | -185°C | Outer Vessel Material: | Carbon Steel |
| Inner Vessel Pressure: | 1.6 MPa | Weight: | 1000 |
| Working Pressure: | 8bar/16bar | Shape: | Cylindrical |
| إبراز: | horizontal underground fuel storage tank,double wall fuel storage tank,large capacity cryogenic storage tank,double wall fuel storage tank,large capacity cryogenic storage tank |
||
| Attribute | Value |
|---|---|
| Inner Cylinder Material | Stainless Steel |
| Max Working Pressure | 2.16 MPa |
| Operating Temperature | -185°C |
| Outer Vessel Material | Carbon Steel |
| Inner Vessel Pressure | 1.6 MPa |
| Weight | 1000 kg |
| Working Pressure | 8 bar / 16 bar |
| Shape | Cylindrical |
Our horizontal cylindrical oil tanks are engineered for superior performance in demanding applications. Their robust construction withstands high positive and negative pressures, significantly reducing oil product evaporation losses and fire risks.
Designed for efficiency, these tanks are factory-manufactured in batches and transported to site for installation, offering excellent mobility and handling convenience. While individual units have moderate capacities, their modular design allows for flexible configurations to meet various storage requirements.
Ideal applications include:
| Storage Medium | Effective Volume | Max Working Pressure | Design Pressure | Main Material |
|---|---|---|---|---|
| LO2, LN2, LAr, LNG | 3 m³ | 0.78 MPa | 0.92 MPa | 06Cr19Ni10/Q245R |
| LO2, LN2, LAr, LNG | 50 m³ | 0.78 MPa | 0.92 MPa | 06Cr19Ni10/Q245R |
| LO2, LN2, LAr, LNG | 350 m³ | 0.78 MPa | 0.92 MPa | 06Cr19Ni10/Q245R |
| LCO2 | 5 m³ | 2.16 MPa | 2.37 MPa | 16MnDR/Q245R |
| LCO2 | 50 m³ | 2.16 MPa | 2.37 MPa | 16MnDR/Q245R |
| LCO2 | 350 m³ | 2.16 MPa | 2.37 MPa | 16MnDR/Q245R |
As professional manufacturers of large storage tanks, we provide comprehensive solutions including design, material supply, and overseas installation. Our engineering team adheres to international standards to deliver tanks in various specifications and materials tailored to your specific requirements.
For more information about our products, please contact us at info@gneeheatex.com. Our team is ready to assist you with your storage tank needs.
